U-DIM-RICO HR Adjustable Recessed Downlight (Integrated)


     Specification Sheet
Product Code:

F53500RC

Electrical Data
Nominal Voltage (V) DC16-21V
Input Current (mA) 350
Product Data
Product Wattage (W) 6.5
Beam Angle (°) 36
Colour Temperature (K) Warmwhite (2800K), Coolwhite (4000K)
Colour Brushed Nickel (NI53), Silver (SV26), White (WH26)
Materials Metal housing with hybrid reflector
Protection Class Class III
Dimmable Yes
Suggested Driver LD0509x1d-C350
Application Corridors, Display Shelves, Hotels, Kitchen Cabinets and Counters, Offices, Shopping Malls, Shops, Study Rooms, Wardrobes, Workstations
Performance Data
Max. Luminous Intensity (cd) 1100
Luminous Flux (lm) 550 [2800K], 500 [4000K]
Luminous Efficacy (lm/W) 77
Rated Life (hrs) 25000
IP Rating IP44
Product Dimensions
Diameter (mm) 80
Height (mm) 30
Cut-out (mm) 68
Remarks
External driver with output current of 350mA and nominal voltage of DC16-21V is required. Capable of linear dimming when working with DALI, DSI or 1-10V dimming drivers, and the dimming performance depends on the specification of driver.
